Length
PE100 Polyethylene Pipe Metric DN125 SDR11 x 12 m Co-Ex Lilac
System PE Systems
Product Code PHXL16125M
Product Properties
Size/Diameter
125MM
Length
12M
Primary Material
POLYETHYLENE
Primary Unit of Measure
LE
Joint Type
Electrofusion, compression, butt-weld, mechanical
Colour
Purple Coating
Coating Specification
Lilac
Allowable Operating Temperature - Degrees
Refer Page 3_Table 2 | https://www.iplex.com.au/assets/Uploads/dc73cc0a04/POLIplex-PE-Pipes-Fittings-Technical-Guide.pdf
Allowable Operating Pressure - 20 Degrees Celsius
1600 kPa @ 20°C
Minimum Radius of Curvature
15 (x DN) Ref: POP202 Nov2016
Unprotected UV Exposed
2 years in accordance with AS/NZS 2033:2008
Maximum Support Spacing of Pipe Graded
1.70m
Maximum Support Spacing of Pipe Vertical
3.40m
Industry Specific Names
poly pipe, PE, polythene, polyethylene pipe, HDPE
Secondary Unit Measure
LE
B2B Pack UOM
Crate
B2B Pack Quantity
26
Product Dimensions
Size/Diameter
125MM
Weight
49.26 kg
Crate Quantity
26
Wall Thickness
11.4mm
Maximum Wall Thickness
114
Minimum Wall Thickness
114
Standards & Accreditations
Product Standard
View
