Length
80 AUSTEL PIPE SWJ X6M WHT AUSTEL TS009
System PVC Non Pressure
Product Code P900806
Overview
- Australian Made
- BEP PVC - Manufactured from Best Environmental Practice PVC
- Installation economics
- Operation efficiencies
- Corrosion resistant
- Light weight
- Electrically nonconductive
Product Properties
Size/Diameter
80MM
Length
6.0M
Primary Material
PVC
Primary Unit of Measure
LE
Joint Type
Solvent Weld Joint
Colour
White
Allowable Operating Temperature - Degrees
60°C
Minimum Radius of Curvature
24m
Socket Deflection
0
Unprotected UV Exposed
2 Years
Maximum Support Spacing of Pipe Graded
1.2m
Markings
Material/Size/PN or SN rating/Applicable Australian Standard
Secondary Unit Measure
LE
B2B Pack UOM
Crate
B2B Pack Quantity
81
Product Dimensions
Size/Diameter
80MM
Weight
6.7 kg
Crate Quantity
81
Crate Weight
542.7kg
Maximum Wall Thickness
4.1
Minimum Wall Thickness
3.5
Socket Length
73
Socket Mouth Diameter
89.2
Socket Root Diameter
88.3
Wall Skin Thickness
0.3
