762mm W x 2068mm L Clear Opening, Ductile Iron, Concrete Infill Cover and Frame Assembly, 3 Part Cover, Class B

Rectangular Cover & Frame

System Metals

Product Code GM303C7620B

Size/Diameter 750 mm

Primary Material OTHER

Primary Unit of Measure EA

Number of Parts 3

Load Class B

Markings None

Secondary Unit Measure EA

Size/Diameter 750 mm

Weight 230.0 kg

Clear Opening - W x L 762 x 2070

GM302C7611G

762mm W x 1143mm L Clear Opening, Ductile Iron, Concrete Infill Cover and Frame Assembly, 2 Part Cover, Class G

GM302S6112D

610mm W x 1290mm L Clear Opening, Ductile Iron, Solid Top Cover and Frame Assembly, 2 Part Cover, Class D

GM302C9112G

914mm W x 1296mm L Clear Opening, Ductile Iron, Concrete Infill Cover and Frame Assembly, 2 Part Cover, Class G

GM302C9118B

914mm W x 1871mm L Clear Opening, Ductile Iron, Concrete Infill Cover and Frame Assembly, 2 Part Cover, Class B

GM303C7624D

762mm W x 2426mm L Clear Opening, Ductile Iron, Concrete Infill Cover and Frame Assembly, 3 Part Cover, Class D

GM302C9114B

914mm W x 1415mm L Clear Opening, Ductile Iron, Concrete Infill Cover and Frame Assembly, 2 Part Cover, Class B

GM302C6114G

610mm W x 1448mm L Clear Opening, Ductile Iron, Concrete Infill Cover and Frame Assembly, 2 Part Cover, Class G

GM303C9123B

914mm W x 2372mm L Clear Opening, Ductile Iron, Concrete Infill Cover and Frame Assembly, 3 Part Cover, Class B

GM302S6114D

610mm W x 1442mm L Clear Opening, Ductile Iron, Solid Top Cover and Frame Assembly, 2 Part Cover, Class D

GM303C6119D

610mm W x 1970mm L Clear Opening, Ductile Iron, Concrete Infill Cover and Frame Assembly, 3 Part Cover, Class D
