PE100 Polyethylene Pipe Metric DN400 SDR11 x 12 m Black with Cream Stripe

Back to all products

Length

PE100 Polyethylene Pipe Metric DN400 SDR11 x 12 m Black with Cream Stripe

System PE Systems

Product Code PCH16400M

Overview

Technical Guide View

Product Properties

Size/Diameter 400MM

Length 12M

Primary Material POLYETHYLENE

Primary Unit of Measure LE

Joint Type Electrofusion, compression, butt-weld, mechanical

Colour Black with cream stripe

Allowable Operating Temperature - Degrees Refer Page 3_Table 2 | https://www.iplex.com.au/assets/Uploads/dc73cc0a04/POLIplex-PE-Pipes-Fittings-Technical-Guide.pdf

Allowable Operating Pressure - 20 Degrees Celsius 1600 kPa @ 20°C

Minimum Radius of Curvature 15 (x DN) Ref: POP202 Nov2016

Unprotected UV Exposed 2 years in accordance with AS/NZS 2033:2008

Maximum Support Spacing of Pipe Graded 1.50m (If longer spans required, refer Iplex Sales Engineer)

Maximum Support Spacing of Pipe Vertical 3.00m

Industry Specific Names poly pipe, PE, polythene, polyethylene pipe, HDPE

Secondary Unit Measure LE

B2B Pack UOM Crate

B2B Pack Quantity 2

Product Dimensions

Size/Diameter 400MM

Weight 506.24 kg

Crate Quantity 2

Wall Thickness 36.3mm

Maximum Wall Thickness 363

Minimum Wall Thickness 363

Standards & Accreditations

Product Standard View
